滑板上面最大回转直径Swing over cross slide                           中300mm

最大的车削直径 Max.turning diameter                                  中300mm

最大的车削长度 Max.turning length                                      200mm

主轴

Spindle

主轴转速Spindle speed                                XKC7530A/C:50～4500rpm

主车由通孔直率 hale diameter                                           φ56mm

主轴可通过棒料直径 Max. diameter of bars  45mm(卡盘/Chuck)/φ45mm(筒夹/Collet)

主电机 Main motor                                        XKC7540A/C:11/15KW

刀架

Turret

刀位数 Number of stations                                                  12

刀具尺寸(车削/堂孔)Toolsize                                     20×20/φ32mm

尾座

Tailstock

套筒直径 tailstock dia                                                 φ90mm

顶尖锥度 center taper                                 莫氏NO.5高精度回转顶尖

套筒行程 tailstock quill travel                                        90mm

始

X轴行程 TravelX                                                        450mm

Z轴行程 Travel Z                                                       400mm

快速移动速度(X/Z) Rapid feed x/Z                                      24m/min

进给电机(X/Z) Feed motors                                   X/Z伺服1.8/2.5KW

任7640C)

最小控制角度(C韩) Min.control angle                         0.001°(Bzi漏码器)

其他

Others

中空液压卡盘 Chuck                                                        8"

中空液压缸 Rotating hydraulic cylinder                                     6"

电源容量(KVA) Required electric power                                  15KVA

机床尺寸(长X宽X高)overalldimension                            2700X1650X1780

机床重量Mass of machine                                           ( 约 ) 3 5 0 0 K g
